| HGW45HA滑块、HGW55CA滑块、HGW55HA滑块、HGW65CA滑块、HGW65HA滑块 |
|
|
|
型號 |
組件尺寸
(mm) |
滑塊尺寸
(mm) |
|
H |
H1 |
N |
W |
B |
B1 |
C |
L1 |
L |
G |
M |
T |
T1 |
H2 |
H3 |
|
HGW 15CA |
24 |
4.3 |
16 |
47 |
38 |
4.5 |
30 |
39.4 |
61.4 |
5.3 |
M5 |
6 |
8.9 |
4.5 |
5.5 |
|
HGW 20CA
HGW 20HA |
30 |
4.6 |
21.5 |
63 |
53 |
5 |
40 |
50.5
65.2 |
77.5
92.2 |
12 |
M6 |
8 |
10 |
6 |
7 |
|
HGW 25CA
HGW 25HA |
36 |
5.5 |
23.5 |
70 |
57 |
6.5 |
45 |
58
78.6 |
84
104.6 |
12 |
M8 |
8 |
14 |
6 |
9 |
|
HGW 30CA
HGW 30HA |
42 |
6 |
31 |
90 |
72 |
9 |
52 |
70
93 |
97.4
120.4 |
12 |
M10 |
8.5 |
16 |
6.5 |
10.8 |
|
HGW 35CA
HGW 35HA |
48 |
7.5 |
33 |
100 |
82 |
9 |
62 |
80
105.8 |
112.4
138.2 |
12 |
M10 |
10.2 |
18 |
9 |
12.6 |
|
HGW 45CA
HGW 45HA |
60 |
9.5 |
37.5 |
120 |
100 |
10 |
80 |
97
128.8 |
139.4
171.2 |
12.9 |
M12 |
16 |
22 |
8.5 |
20.5 |
|
HGW 55CA
HGW 55HA |
70 |
13 |
43.5 |
140 |
116 |
12 |
95 |
117.7
155.8 |
166.7
204.8 |
12.9 |
M14 |
17.5 |
26.5 |
12 |
19 |
|
HGW 65CA
HGW 65HA |
90 |
15 |
53.5 |
170 |
142 |
14 |
110 |
144.2
203.6 |
200.2
259.6 |
12.9 |
M16 |
25 |
37.5 |
15 |
15 |
|
滑軌尺寸
(mm) |
滑軌的
固定
螺栓
尺寸
(mm) |
基本
動額定
負荷
C(kN) |
基本
靜額定
負荷
C0(kN) |
容許靜力距 |
重量 |
|
MR
(kN-m) |
MP
(kN-m) |
MY
(kN-m) |
滑塊
(kg) |
滑軌
(kg/m) |
|
WR |
HR |
D |
h |
d |
P |
E |
|
15 |
15 |
7.5 |
5.3 |
4.5 |
60 |
20 |
M4 x 16 |
11.38 |
25.31 |
0.17 |
0.15 |
0.15 |
0.17 |
1.45 |
|
20 |
17.5 |
9.5 |
8.5 |
6 |
60 |
20 |
M5 x 16 |
17.75
21.18 |
37.84
48.84 |
0.38
0.48 |
0.27
0.47 |
0.27
0.47 |
0.40
0.52 |
2.21 |
|
23 |
22 |
11 |
9 |
7 |
60 |
20 |
M6 x 20 |
26.48
32.75 |
56.19
76.00 |
0.64
0.87 |
0.51
0.88 |
0.51
0.88 |
0.59
0.80 |
3.21 |
|
28 |
26 |
14 |
12 |
9 |
80 |
20 |
M8 x 25 |
38.74
47.27 |
83.06
10.13 |
1.06
1.40 |
0.85
1.47 |
0.85
1.47 |
1.09
1.44 |
4.47 |
|
34 |
29 |
14 |
12 |
9 |
80 |
20 |
M8 x 25 |
49.52
60.21 |
102.87
136.31 |
1.73
2.29 |
1.20
2.08 |
1.20
2.08 |
1.56
2.06 |
6.30 |
|
45 |
38 |
20 |
17 |
14 |
105 |
22.5 |
M12 x 35 |
77.57
94.54 |
155.93
207.12 |
3.01
4.00 |
2.35
4.07 |
2.35
4.07 |
2.79
3.69 |
10.41 |
|
53 |
44 |
23 |
20 |
16 |
120 |
30 |
M14 x 45 |
114.44
139.35 |
227.81
301.26 |
5.66
7.49 |
4.06
7.01 |
4.06
7.01 |
4.52
5.96 |
15.08 |
|
63 |
53 |
26 |
22 |
18 |
150 |
35 |
M16 x 50 |
163.63
208.36 |
324.71
457.15 |
10.02
14.15 |
6.44
11.12 |
6.44
11.12 |
9.17
12.89 |
21.18 |
|
|
|
|
