轴径	轴承型号		重量	外形尺寸			额定负荷		极限转速
	Bearing Designation		Mass	BoundaryDimensions			BasicLoadRating		Limiting Speed
Shaft	现型号	原型号	Approx	Fw	D	C	动	静	油润滑 Oil
	CurrentCode	OriginalCode					Dynamic	Static
mm			g	mm			N		rpm
20	K20X24X10	29241/20	6.5	20	24	10	8700	12100	19000
	K20X24X12		8	20	24	12	9600	13800	19000
	K20X24X13	39241/20	8.9	20	24	13	9600	13800	19000
	K20X24X17	59241/20	11.2	20	24	17	12400	20000	19000
	K20X26X12	19243/20	13.2	20	26	12	13100	15700	19000
	K20X26X16	K9249/20	17.5	20	26	16	18000	25000	18500
	K20X26X17	39243/20	18.2	20	26	17	18700	25500	19000
	K20X26X20	49243/20	22	20	26	20	20600	28500	19000
	K20X28X20	19245/20	26.8	20	28	20	23400	28000	18000
	K20X28X25	29245/20	36.2	20	28	25	30000	28500	18000
	K20X30X30	39245/20	56	20	30	30	35000	41000	18000
21	K21X25X13		9	21	25	13	9600	14500	19000
	K21X25X17		12	21	25	17	12800	21000	19000
22	K22X26X10	29241/22	7.1	22	26	10	8700	12900	18000
	K22X26X13	39241/22	9.4	22	26	13	10000	15400	18000
	K22X26X17	59241/22	12.1	22	26	17	13100	22100	18000
	K22X27X13	29242/22	10.8	22	27	13	14000	23000	18000
	K22X28X17	39243/22	19.7	22	28	17	19000	26500	18000
	K22X28X23	59243/22	26	22	28	23	20000	27000	19000
	K22X29X16	19244/22	22.2	22	29	16	19500	25000	17000
	K22X30X15TN		14.4	22	30	15	19600	22900	17000
	K22X30X20	19245/22	28	22	30	20	21000	23500	18900
	K22X32X24		43.4	22	32	24	33500	39500	16000
23	K23X35X16TN		30	23	35	16	24000	23400	15000
24	K24X28X10		8.1	24	28	10	9400	14300	17000
	K24X28X13		10.1	24	28	13	10500	17000	17000
	K24X28X17	9243/24	13.2	24	28	17	14000	24500	17000
	K24X29X13		13.5	24	29	13	13100	19100	16000
	K24X30X17		21.5	24	30	17	19000	27000	16000
	K24X30X31		39.1	24	30	31	27000	43000	16000
25	K25X29X10	29241/25	8.3	25	29	10	9700	14900	16000
	K25X29X13	39241/25	10.4	25	29	13	10800	17900	16000
	K25X29X17	59241/25	13.7	25	29	17	14500	25500	16000
	K25X30X13	29242/25	12.9	25	30	13	14100	21300	16000
	K25X30X20	59242/25	20.5	25	30	20	21100	28000	16000
	K25X30X25		21	25	30	25	21700	40400	15000
	K25X30X26	SZ-636	21.6	25	30	26	20100	26500	15000
	K25X31X17	39243/25	21.8	25	31	17	19000	28000	16000
	K25X31X21	39243/25	26.2	25	31	21	24100	37500	16000
	K25X32X16	19244/25	24.5	25	32	16	20500	27500	15000
	K25X33X20	19245/25	32	25	33	20	28000	37500	15000
	K25X33X24	29245/25	38.7	25	33	24	33900	46500	15000
	K25X34X18		32	25	34	18	48000	67000	15000
	K25X35X30	39245/25	65.5	25	35	30	46500	61500	14000
	K25X30X26 ZW		27	25	30	26	21000	35000	14000
