轴承型号	基本尺寸			基本额定载荷		疲劳载荷极限	额定转速	Limiting
	Principal dimensions			动态	静态		参考转速
Bearing	d / d1	D	B	C	C0	Pu	r	speed
	mm			kN		kN	min
C2212KTN9+H312E	55	110	28	143	156	18.3	5600	7500
C2211KV	55	100	25	132	134	15.6		3400
C2212KV+H312	55	110	28	166	190	22.4		2800
C2211KTN9	55	100	25	116	114	13.4	6300	9000
C6911V	55	80	45	180	300	35.5		2200
C2212KV+AHX312	55	110	28	166	190	22.4		2800
C2211TN9	55	100	25	116	114	13.4	6300	9000
C2212KTN9+AHX312	55	110	28	143	156	18.3	5600	7500
C2211V	55	100	25	132	134	15.6		3400
C2212TN9	60	110	28	143	156	18.3	5600	7500
C2213KTN9+AH313G	60	120	31	180	180	21.2	5300	7500
C2213KV+AH313G	60	120	31	204	216	25.5		2400
C2314K+H2314	60	150	51	405	430	49	3800	5000
C2213KV+H313	60	120	31	204	216	25.5		2400
C2213KTN9+H313E	60	120	31	180	180	21.2	5300	7500
C6912V	60	85	45	190	335	39		1900
C2212KTN9	60	110	28	143	156	18.3	5600	7500
C2212KV	60	110	28	166	190	22.4		2800
C2214KTN9+H314E	60	125	31	186	196	22.8	5000	7000
C6912-2NSV	60	85	45	190	335	39
C2212V	60	110	28	166	190	22.4		2800
C4013-2CS5V/GEM9	65	100	35	102	173	20.4		150
C2215K+H315E	65	130	31	196	208	24	4800	6700
C2215KV+H315	65	130	31	220	240	28		2200
C2213KV	65	120	31	204	216	25.5		2400
C2314K+AHX2314G	65	150	51	405	430	49	3800	5000
C2213KTN9	65	120	31	180	180	21.2	5300	7500
C2315K+H2315	65	160	55	425	465	52	3600	4800
C2213V	65	120	31	204	216	25.5		2400
C2213TN9	65	120	31	180	180	21.2	5300	7500
C2214KTN9+AH314G	65	125	31	186	196	22.8	5000	7000
